ASUS TUF Gaming FX507VU-LP285-GAMING RAM upgrade specifications
The ASUS TUF Gaming F15 FX507VU-LP285-GAMING laptop features DDR5-SDRAM memory upgrades with two SO-DIMM slots supporting maximum capacity of 32 GB total. Memory operates at 4800 MHz frequency. Compatible DDR5 SO-DIMM modules can be installed in either slot for RAM upgrades. Specifications indicate support for DDR5 technology with dual-slot configuration, allowing users to expand memory capacity up to the maximum supported 32 GB limit. Memory upgrades utilize standard SO-DIMM form factor components.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The dual-channel architecture requires 2 matching modules to reach maximum memory bandwidth and prevent CPU performance bottlenecks during heavy gaming or rendering tasks.
- The 32 GB capacity threshold is enforced by the hardware BIOS or chipset limitations, meaning higher density modules will likely result in a failure to boot.
- Installing modules with higher frequency ratings than 4800 MHz will result in downclocking to the system default speed because the motherboard chipset lacks support for faster profiles.
- Accessing the SO-DIMM slots on the ASUS FX507VU-LP285-GAMING requires removing the bottom chassis panel, which exposes internal components to potential electrostatic discharge risks.
- The use of DDR5 technology introduces on-die ECC and improved power management compared to the previous DDR4 standard, but it is not backward compatible with physically identical DDR4 slots.
- Operating with a single populated slot creates a single-channel memory configuration, which significantly reduces data transfer rates and slows down frame rates in CPU-bound applications.
- Future memory expansions are limited to replacing existing modules rather than adding new ones once both slots are occupied, making a 16 GB per slot configuration the final upgrade path.
- Latency timings are automatically negotiated via the Serial Presence Detect chip on the RAM, so mixing modules with different CAS latencies will force all memory to run at the slowest common denominator.
