ASUS TUF Gaming FX507ZC4-HN002 RAM upgrade specifications
ASUS TUF Gaming F15 FX507ZC4-HN002 laptop features two SO-DIMM memory slots compatible with DDR5-SDRAM modules. Maximum RAM capacity reaches 32 GB total, supporting DDR5-4800 MHz specifications. Upgrade options enable installation of compatible DDR5 memory modules to expand system RAM performance. Current memory slots accommodate dual SO-DIMM form factor upgrades for enhanced multitasking and application performance capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 27 September 2022 |
Additional Notes
- Dual channel memory architecture requires populated pairs of identical modules to achieve maximum theoretical memory bandwidth for the processor.
- The 32 GB threshold represents the maximum validated capacity through the memory controller and may restrict future high density module compatibility.
- Utilizing DDR5 technology in the ASUS TUF Gaming FX507ZC4-HN002 provides higher base clock speeds than previous generations but also introduces higher initial CAS latency overhead.
- Physical access to both SO-DIMM slots typically necessitates the removal of the entire base panel which involves navigating internal thermal pads and sensitive plastic clips.
- Installing modules with frequencies exceeding 4800 MHz results in automatic downclocking to match the system firmware limitations.
- Memory upgrades do not require soldering and allow for non-destructive hardware changes that maintain the primary motherboard warranty status.
- The transition from a single module to a dual module configuration significantly improves integrated graphics performance and frame time consistency in gaming workloads.
