ASUS TUF Gaming FX507ZC4-HN083W RAM upgrade specifications
ASUS TUF Gaming F15 series FX507ZC4-HN083W laptop memory upgrade specifications include two SO-DIMM slots supporting DDR4-SDRAM memory modules. Maximum RAM capacity reaches 32 GB total, with compatible memory operating at 3200 MHz frequency. The SO-DIMM form factor specifications define upgrade compatibility for the FX507ZC4-HN083W model. Memory upgrades utilize DDR4 technology with dual-slot configuration, enabling users to expand system memory to the maximum specifications of 32 GB RAM capacity.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 08 February 2023 |
Additional Notes
- The ASUS TUF Gaming FX507ZC4-HN083W uses SO-DIMM slots, which means replacement modules must be laptop-specific memory and cannot be substituted with standard desktop DDR4 modules.
- With 2 slots populated to a 32 GB ceiling, upgrading beyond the factory configuration requires removing existing modules; there is no expansion path without replacement rather than addition.
- DDR4-3200 MHz memory operates at a fixed speed on this platform. Third-party modules rated above 3200 MHz will downclock to 3200 MHz, eliminating any performance advantage from higher-frequency memory.
- Single-channel to dual-channel transitions occur only when both SO-DIMM slots contain matching capacity modules; mismatched configurations reduce bandwidth efficiency and eliminate dual-channel benefits even if both slots are occupied.
- The DDR4 specification on this laptop ended mainstream platform support in 2021; future driver and BIOS updates will become infrequent, restricting compatibility with emerging memory standards and reducing the warranty-safe upgrade window.
- SO-DIMM physical constraints impose a compact form factor that limits heatspreader design; passive thermal management on replacement modules may affect stability under sustained gaming workloads if thermal specifications differ from OEM memory.
- Dual 16 GB modules represent the only path to 32 GB capacity; single 32 GB SO-DIMM modules are unavailable in DDR4 technology, making the maximum upgrade rigid rather than flexible.
