ASUS TUF Gaming FX507ZC4-HN158 RAM upgrade specifications
ASUS TUF Gaming F15 FX507ZC4-HN158 features two SO-DIMM slots supporting DDR4-SDRAM memory at 3200 MHz frequency. Maximum RAM capacity reaches 32 GB total. Compatible memory upgrades utilize SO-DIMM form factor specifications. Current configuration and available slots allow for memory expansion to achieve maximum supported capacity. RAM upgrade options maintain compatibility with existing system architecture and specifications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
Additional Notes
- The presence of 2 physical SO-DIMM slots implies that reaching the 32 GB maximum capacity requires a dual-channel configuration of 16 GB modules to maximize memory bandwidth.
- Utilization of DDR4-SDRAM architecture prevents the installation of newer DDR5 modules due to incompatible pin counts and differing voltage requirements.
- System stability on the ASUS TUF Gaming FX507ZC4-HN158 depends on selecting non-ECC unbuffered modules since the chipset lacks the parity circuitry required for error-correcting code memory.
- Latency performance is governed by the 1.2V JEDEC standard which means choosing modules with lower CL timings at 3200 MHz will improve data processing speeds without requiring BIOS overclocking.
- Dual-slot accessibility facilitates a symmetrical memory setup which is critical for preventing integrated graphics bottlenecks and ensuring balanced CPU thread performance.
- Hardware upgrades performed via the bottom access panel typically remain within warranty bounds provided no internal components suffer physical damage during the installation of 260-pin modules.
- Total addressable memory is capped at 32 GB by the firmware and motherboard traces regardless of whether the operating system or processor can technically support higher densities.
