ASUS TUF Gaming FX507ZC4-HN205 RAM upgrade specifications
ASUS TUF Gaming F15 FX507ZC4-HN205 features two SO-DIMM slots supporting DDR4-SDRAM memory modules. Compatible RAM operates at 3200 MHz frequency with maximum capacity of 32 GB total. Upgrade specifications allow installation of compatible DDR4 memory modules in both slots to achieve maximum supported memory configuration. Memory slots accept standard SO-DIMM form factor components meeting DDR4 standards.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
Additional Notes
- The presence of 2 SO-DIMM slots allows for a dual-channel memory configuration which increases data bandwidth compared to single-channel setups.
- Upgrading the ASUS TUF Gaming FX507ZC4-HN205 to the 32 GB threshold requires the replacement of existing modules if both slots are occupied from the factory.
- The DDR4 architecture limits the peak theoretical transfer rate to 25.6 GB/s per channel due to the 3200 MHz frequency cap.
- Latency performance depends on the CAS latency of the installed kits as the motherboard will default to the highest common denominator between disparate modules.
- Installation of memory modules exceeding the 3200 MHz rating will result in automatic downclocking to match the integrated memory controller specifications.
- Technical maintenance of the internal hardware requires a standard Phillips head driver and a non-conductive prying tool to release the plastic clips of the bottom chassis panel.
- Voltage requirements for compatible modules are 1.2V as higher voltage XMP profiles are rarely supported in this hardware category.
