ASUS TUF Gaming FX507ZC4-HN226W RAM upgrade specifications
ASUS TUF Gaming F15 model FX507ZC4-HN226W features DDR4-SDRAM memory upgrade specifications. The laptop includes 2x SO-DIMM slots compatible with DDR4 modules operating at 3200 MHz frequency. Maximum memory capacity reaches 32 GB when both slots are populated with compatible upgrades. RAM upgrades utilize SO-DIMM form factor modules. Specifications support DDR4-SDRAM technology for memory expansion and performance enhancement.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
Additional Notes
- The ASUS TUF Gaming FX507ZC4-HN226W accepts a maximum of 32 GB total, implying that each SO-DIMM slot supports up to 16 GB modules when populated with matching capacity sticks.
- DDR4-3200 represents the native supported frequency, while higher-rated modules will typically downclock to match this specification if installed.
- The dual SO-DIMM architecture enables dual-channel memory operation when identical modules occupy both slots, doubling theoretical bandwidth compared to single-channel configurations.
- Mismatched module capacities or timings between the 2 slots may force the system into asymmetric or single-channel mode, reducing memory subsystem throughput.
- SO-DIMM form factor physically differs from desktop DIMM modules, requiring laptop-specific memory modules with the shorter 260-pin connector.
- The 32 GB ceiling reflects chipset or motherboard limitations rather than DDR4 technology constraints, as the standard itself supports higher densities.
- Memory upgrades typically preserve manufacturer warranty when performed without disassembling soldered components, though confirmation through warranty documentation remains advisable.
- Mixing DDR4 generations with different voltage requirements or non-standard XMP profiles may cause POST failures or stability issues during operation.
- The 3200 MHz specification indicates PC4-25600 rating equivalency, which should be verified on replacement module packaging to ensure compatibility.
- Both slots being user-accessible suggests no soldered memory configuration, allowing complete replacement rather than requiring supplementation of fixed modules.
