ASUS TUF Gaming FX507ZU4-LP050W RAM upgrade specifications

ASUS FX507ZU4-LP050W ASUS FX507ZU4-LP050W ASUS FX507ZU4-LP050W ASUS FX507ZU4-LP050W ASUS FX507ZU4-LP050W

ASUS TUF Gaming F15 FX507ZU4-LP050W RAM upgrade specifications include two SO-DIMM slots supporting DDR4-SDRAM memory operating at 3200 MHz frequency. Maximum memory capacity reaches 32 GB total. Compatible upgrades utilize SO-DIMM form factor modules. Memory specifications define upgrade compatibility and available capacity options for the FX507ZU4-LP050W laptop model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s

Additional Notes

  • The presence of 2 physical SO-DIMM slots signifies that the system relies on a dual-channel architecture for optimal memory bandwidth.
  • Upgrading the ASUS FX507ZU4-LP050W to 32 GB requires two 16 GB modules to utilize the full addressable capacity allowed by the firmware.
  • Installation of memory modules with frequencies exceeding 3200 MHz will result in automatic downclocking to match the internal bus limitations.
  • The hardware architecture utilizes a non-soldered configuration allowing for the total replacement of factory-installed modules without specialized tools.
  • Memory latency performance depends on the installation of matched pairs to prevent the motherboard from defaulting to the timings of the slowest stick.
  • Accessing the internal slots for maintenance or upgrades requires the removal of the bottom chassis panel which may involve breaking factory tamper seals depending on regional service policies.
  • The 32 GB limit indicates a bios-level ceiling that prevents the recognition of high-density 32 GB single sticks for 64 GB total configurations.
