ASUS TUF Gaming FX706HC-HX075W RAM upgrade specifications
ASUS TUF Gaming F17 series FX706HC-HX075W laptop features two SO-DIMM slots supporting DDR4-SDRAM memory modules. Maximum RAM capacity reaches 32 GB total. Memory upgrade specifications include DDR4 operating frequency of 3200 MHz. Compatible memory modules utilize SO-DIMM form factor. Current configuration and upgrade potential dependent on existing installed memory capacity. Specifications enable RAM expansion for enhanced multitasking and application performance on gaming-class notebook platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 13 July 2022 |
Additional Notes
- The dual-slot configuration allows for a symmetrical dual-channel architecture to maximize memory bandwidth for the integrated and discrete graphics processors.
- Upgrading the ASUS TUF Gaming FX706HC-HX075W requires non-ECC unbuffered modules to ensure system stability and POST compatibility.
- Reaching the 32 GB threshold necessitates the replacement of any existing low-capacity factory modules since no additional vacant slots reside on the motherboard.
- The 3200 MHz frequency reflects the peak native JEDEC speed for the platform and will downclock automatically if paired with lower-rated modules.
- Physical installation demands standard 260-pin SO-DIMM hardware which is distinct from the larger desktop DIMM equivalent.
- Latency performance depends on matching the CAS latency of both sticks to avoid the motherboard defaulting to the slowest shared timing profile.
- Accessing the memory slots involves removing the base chassis cover which may require plastic pry tools to avoid damaging the internal retention clips.
