ASUS TUF Gaming FX707ZC4-HX049W RAM upgrade specifications
ASUS TUF Gaming F17 series model FX707ZC4-HX049W features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum capacity of 32 GB total. Compatible RAM operates at 3200 MHz frequency using SO-DIMM form factor. Upgrade configurations allow installation of memory modules in both available slots to achieve maximum supported capacity. Specifications indicate DDR4 memory compatibility for this TUF Gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
Additional Notes
- Dual channel memory architecture requires matching module capacities and speeds across both slots to achieve maximum theoretical memory bandwidth for the ASUS TUF Gaming FX707ZC4-HX049W.
- Upgrading beyond 32 GB is restricted by firmware limitations despite the processor supporting higher capacities in other hardware configurations.
- The choice of DDR4 memory limits the system to lower data transfer rates compared to newer DDR5 platforms while maintaining lower latency and better power efficiency at 1.2 volts.
- Accessing the SO-DIMM slots involves bottom panel removal which requires plastic pry tools to avoid damaging the chassis clips or internal grounding foil.
- Installing modules with speeds higher than 3200 MHz results in automatic downclocking to match the hard-coded BIOS memory profile.
- Replacing factory modules with high-density components must account for physical clearance against heat shielding and adjacent cooling pipes.
- System stability depends on using non-ECC unbuffered modules because the motherboard chipset lacks support for error-correcting code functions.
