ASUS TUF Gaming FX707ZM-HX049W RAM upgrade specifications
ASUS TUF Gaming F17 series FX707ZM-HX049W laptop features two SO-DIMM memory slots supporting DDR5-SDRAM upgrade capacity. Maximum RAM specifications indicate 32 GB total supported memory at 4800 MHz frequency. Compatible memory upgrades utilize SO-DIMM form factor for this gaming laptop model. RAM upgrade slots accept DDR5 modules to expand system memory specifications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 January 2022 |
Additional Notes
- The specified maximum capacity suggests a motherboard firmware limitation or a thermal validation threshold rather than a CPU architectural cap.
- Utilizing both SO-DIMM slots is required to enable dual-channel memory mode for optimized bandwidth in the ASUS TUF Gaming FX707ZM-HX049W.
- Installing modules with lower latency timings than the factory defaults will result in a downclock to the highest supported JEDEC profile stored in the BIOS.
- Upgrading beyond the 4800 MHz frequency provides no performance benefit as the system will automatically throttle higher speed kits to the rated bus speed.
- The 2 slot physical configuration necessitates the removal of existing modules to reach the 32 GB limit since no memory is soldered to the mainboard.
- Power consumption and heat generation scale with increased density, potentially impacting the thermal headroom of the cooling solution during sustained workloads.
- Compatibility with high-density 16 GB sticks requires modules to follow the standard 1.1V DDR5 voltage specification to avoid boot failures.
