ASUS Vivobook X412FA RAM upgrade specifications
ASUS Vivobook 14 X412FA RAM upgrade specifications indicate DDR4-SDRAM memory compatibility with maximum capacity of 12 GB. The laptop features 1x SO-DIMM slot for memory expansion alongside on-board memory. Compatible RAM modules operate at 2400 MHz frequency. Upgrade specifications enable users to increase system memory capacity through the available SO-DIMM slot, supporting DDR4-SDRAM modules within the maximum capacity constraints. Memory specifications define compatible upgrades for enhanced multitasking performance.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 02 May 2019 |
Additional Notes
- The ASUS Vivobook X412FA contains soldered on-board memory that cannot be removed, meaning only the single SO-DIMM slot allows for capacity expansion.
- Installation of a 8 GB DDR4-2400 SO-DIMM module represents the only path to reach the 12 GB maximum, as the on-board portion is fixed.
- DDR4-2400 operates at reduced frequency compared to contemporary standards (3200 MHz typical), creating latency disadvantages when paired with newer processors that support faster memory speeds.
- Single-channel memory operation results from the soldered configuration, reducing bandwidth efficiency compared to dual-channel setups that match or exceed the SO-DIMM upgrade's bandwidth contribution.
- The 1x SO-DIMM architecture permits no future scaling beyond 12 GB total capacity; replacement of the module (rather than addition) becomes the only recourse for any subsequent upgrade.
- DDR4-2400 modules are declining in availability as manufacturers phase out production in favor of DDR4-3200 and DDR5 variants, potentially increasing sourcing difficulty and cost for replacements within 2-3 years.
- Warranty policies typically permit SO-DIMM replacement without restrictions, but verification with ASUS support remains necessary before opening the device to confirm coverage applicability on this model.
