ASUS Vivobook X412FL-EB009T RAM upgrade specifications
ASUS Vivobook 14 X412FL-EB009T RAM upgrade specifications include DDR4-SDRAM memory compatible with 1x SO-DIMM slot. The laptop features on-board memory combined with one upgradeable SO-DIMM slot, supporting maximum RAM capacity of 12 GB. Memory operates at 2400 MHz frequency. Upgrade options allow expansion of existing on-board memory configuration through the available SO-DIMM slot to reach maximum supported capacity specifications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 02 August 2019 |
Additional Notes
- The presence of a single SO-DIMM slot alongside hardwired memory creates an asymmetrical dual-channel configuration when capacities do not match.
- The ASUS Vivobook X412FL-EB009T requires a 8 GB module in the accessible slot to reach the hardware limit, as 4 GB is permanently integrated into the motherboard.
- Memory modules with speeds exceeding 2400 MHz will undergo automatic downclocking to match the fixed latency of the soldered hardware.
- Internal component access involves the removal of the bottom chassis cover, which requires precision tools to avoid damage to plastic retention clips.
- Total system bandwidth remains restricted by the slowest physical component, preventing performance gains from high-speed aftermarket kits.
- The integrated memory prevents a full replacement of the primary bank, meaning a failure in the on-board chips necessitates a complete motherboard repair rather than a simple module swap.
- Physical clearance within the slim chassis mandates the use of standard height SO-DIMM modules to ensure the case closes without applying pressure to the silicon.
