ASUS Vivobook X412FL-58AM5SB1 RAM upgrade specifications
ASUS Vivobook 14 Series X412FL-58AM5SB1 features DDR4-SDRAM memory configuration with one SO-DIMM slot available for upgrade. Laptop contains 4GB on-board memory with maximum expandable capacity of 12GB total RAM. Compatible memory module operates at 2400MHz frequency. Upgrade specifications allow installation of single DDR4 SO-DIMM module to achieve maximum memory capacity. Current configuration supports memory expansion through single accessible slot for enhanced multitasking performance.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 01 May 2020 |
Additional Notes
- The ASUS Vivobook X412FL-58AM5SB1 contains soldered memory on the motherboard, meaning only the single SO-DIMM slot can accept upgrades; the on-board portion cannot be replaced or removed.
- A 12 GB maximum configuration requires pairing a 4 GB SO-DIMM module with the fixed on-board memory, creating asymmetrical dual-channel operation that reduces bandwidth efficiency compared to matched memory pairs.
- The 2400 MHz specification represents the maximum supported frequency; actual operating speed depends on BIOS settings and may default to lower frequencies if third-party modules do not match the on-board chip's characteristics.
- DDR4 SO-DIMM modules rated for 2666 MHz or higher will function in this slot but will downclock to 2400 MHz, making premium-speed modules economically inefficient for this platform.
- Thermal constraints in the X412FL compact chassis may affect memory stability if aftermarket modules lack heat dissipation or if the SO-DIMM slot sits in a confined area; passive cooling design limits headroom for marginal memory timings.
- Upgrading beyond 4 GB requires sourcing a matched SO-DIMM; availability of older DDR4-2400 modules has diminished, increasing cost per gigabyte relative to newer memory standards.
- Warranty coverage typically permits single SO-DIMM replacement; installation by the end-user does not void protection if performed correctly without motherboard contact or accidental component damage.
