ASUS Vivobook F512DK-EJ073T-BE RAM upgrade specifications
The ASUS Vivobook 15 F512DK-EJ073T-BE features DDR4-SDRAM memory with one SO-DIMM slot available for upgrade. The laptop includes on-board memory soldered to the motherboard, with maximum RAM capacity of 12 GB. Compatible memory modules operate at 2400 MHz frequency. The upgrade specifications support DDR4 memory technology for enhanced system performance and multitasking capabilities on the F512DK-EJ073T-BE model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 18 March 2019 |
Additional Notes
- The presence of on board memory limits total capacity because the single SO-DIMM slot must accommodate the remaining balance of the 12 GB maximum.
- Installing a module with a frequency higher than 2400 MHz results in automatic downclocking to match the fixed speed of the integrated memory bank.
- Dual channel performance benefits only apply to the portion of the SO-DIMM capacity that matches the size of the soldered on board chips.
- Hardware maintenance on the ASUS Vivobook F512DK-EJ073T-BE requires total removal of the bottom chassis plate to access the internal expansion area.
- Physical memory expansion is restricted to a single point of failure as the integrated memory cannot be replaced if a chip failure occurs.
- Thermal constraints within the slim chassis favor the use of 1.2V low voltage modules to ensure stable operation during high system loads.
- Asynchronous memory configurations consisting of mismatched capacities between the soldered and removable sticks will trigger Intel Flex Memory Technology or the AMD equivalent.
