ASUS Vivobook F512DK-EJ073T-LU RAM upgrade specifications
ASUS Vivobook 15 series model F512DK-EJ073T-LU RAM upgrade specifications include DDR4-SDRAM memory compatibility. The laptop contains one SO-DIMM slot available for upgrade, with maximum RAM capacity of 12 GB total. Memory operates at 2400 MHz frequency. The system features on-board memory combined with SO-DIMM slot configuration. Compatible DDR4 modules can be installed in the available slot to expand memory capacity for enhanced performance and multitasking capabilities on this ASUS Vivobook 15 laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 25 March 2019 |
Additional Notes
- The presence of on board memory indicates that a portion of the system RAM is permanently soldered to the motherboard and cannot be replaced or upgraded.
- System memory expansion is limited to a single physical expansion slot which dictates a strict capacity ceiling for total addressable RAM.
- The ASUS Vivobook F512DK-EJ073T-LU utilizes an asymmetric memory configuration where the dual channel performance benefit only applies to the capacity matched between the soldered chips and the removable module.
- Memory modules with higher native clock speeds will automatically downclock to synchronize with the hardwired memory frequency of the motherboard controller.
- Physical installation requires a standard DDR4 SO-DIMM peripheral while any capacity exceeding 8 GB in the expansion slot will likely remain unaddressable due to hardware firmware limitations.
- Latency timings are governed by the slowest installed component ensuring that the soldered memory module acts as the primary performance baseline for the entire system.
