DELL Inspiron 3482 RAM upgrade specifications
DELL Inspiron 3000 Series model 3482 supports DDR4-SDRAM memory upgrades. The laptop contains one SO-DIMM slot for memory expansion. Maximum RAM capacity reaches 8 GB. Compatible memory modules operate at 2666 MHz frequency. Upgrade specifications indicate SO-DIMM form factor compatibility. Current memory configuration allows single-slot expansion to achieve maximum supported capacity. DDR4-SDRAM technology provides standard memory upgrade options for the 3482 model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 8 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 04 June 2019 |
Additional Notes
- The Dell Inspiron 3482 contains a single memory slot, meaning maximum capacity expansion halts at 8 GB regardless of module density improvements in future DDR4 SO-DIMM products.
- DDR4-2666 operation indicates the memory controller locks at this frequency ceiling; faster DDR4 modules (3200 MHz or above) will throttle down to 2666 MHz, eliminating any bandwidth advantage from premium variants.
- SO-DIMM form factor restricts upgrades to laptop-grade modules exclusively. Desktop DDR4 UDIMM sticks are physically incompatible and cannot be force-fitted without permanent connector damage.
- Single-slot architecture creates a replacement-only upgrade path; installing an 8 GB module requires removing the existing memory module entirely, with no opportunity for capacity stacking.
- The 8 GB ceiling combined with DDR4-2666 bandwidth creates a secondary bottleneck for memory-intensive workloads; applications demanding >8 GB capacity or >21 GB/s throughput will face performance constraints independent of processor capability.
- Warranty coverage typically permits memory upgrades performed by end-users without voiding coverage, provided original modules are retained and installation causes no physical damage to surrounding components or sockets.
