DELL Inspiron 5405 RAM upgrade specifications
The Dell Inspiron 5000 Series 5405 laptop features two SO-DIMM slots for memory upgrades, supporting DDR4-SDRAM modules at 3200 MHz frequency. The maximum RAM capacity for this model is 32 GB, allowing users to expand memory in compatible increments. Specifications indicate SO-DIMM form factor compatibility, with upgrade options available to enhance multitasking performance and overall system responsiveness on the Dell 5405.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 24 June 2020 |
Additional Notes
- Dual channel mode is only achieved when matching modules are installed in both slots to optimize memory bandwidth.
- The maximum capacity limits single slot modules to 16 GB per socket for the Dell Inspiron 5405 hardware configuration.
- Installing memory with higher clock speeds will result in downclocking to the system bus limit of 3200 MHz.
- Physical access to the SO-DIMM slots requires the removal of the base cover and likely the disconnection of the internal battery to prevent electrical short circuits.
- Mixing modules with different CAS latencies will force the system to operate at the timing of the slower module.
- Non-ECC unbuffered memory is the only supported architecture for stable operation within this platform.
- Integrated graphics performance scales directly with the speed and quantity of available system memory because the GPU lacks dedicated VRAM.
