DELL Latitude 5495 RAM upgrade specifications

DELL Latitude 5000 Series 5495 RAM upgrade specifications include DDR4-SDRAM memory compatible with 2x SO-DIMM slots. Maximum memory capacity reaches 32 GB total. Memory modules operate at 2400 MHz frequency. SO-DIMM form factor specifications enable compatible RAM upgrades for the 5495 model. Existing memory configurations support upgrade expansion within the maximum capacity specifications defined for the Latitude 5000 Series.

Additional Notes

• Dual channel memory architecture is achievable only when both slots are occupied with matched modules to enhance memory bandwidth for the integrated Radeon Vega graphics processor.
• Latency parity requires modules with identical CAS latency to prevent the system from defaulting to the highest common timing value.
• Installation of memory modules with frequencies exceeding 2400 MHz results in automatic downclocking to match the hardcoded bus speed of the motherboard chipset.
• The 32 GB ceiling necessitates the use of high density 16 GB individual sticks since the motherboard cannot address 32 GB single stick configurations.
• Access to the SO-DIMM slots requires the removal of the base cover assembly which may involve captive screws and plastic clips prone to fatigue.
• Voltage compatibility is restricted to 1.2V DDR4 standards; utilizing high voltage performance memory causes boot failure or power delivery instability.
• Physical clearance within the chassis restricts memory upgrades to standard height SO-DIMM profiles excluding modules with integrated heat spreaders.
• The absence of soldered memory on the system board allows for 100 percent replacement of factory RAM during the upgrade process.
