DELL Latitude 5521 RAM upgrade specifications
Dell Latitude 5000 Series model 5521 supports DDR4-SDRAM memory upgrades through 2x SO-DIMM slots. Maximum memory capacity reaches 64 GB total. Compatible memory modules operate at 3200 MHz frequency with SO-DIMM form factor specifications. Upgrade options allow expansion of system memory to meet processing demands and multitasking requirements. Memory specifications define compatibility parameters for Dell Latitude 5521 RAM replacement and enhancement.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 05 July 2021 |
Additional Notes
- The Dell Latitude 5521 supports DDR4 memory at 3200 MHz, which represents a bandwidth ceiling of 51.2 GB/s per channel. Dual-channel operation across 2 SO-DIMM slots delivers theoretical throughput of 102.4 GB/s when both slots are populated with matching modules.
- SO-DIMM form factor restricts upgrade options to laptop-specific memory modules. Desktop DDR4 UDIMM sticks are physically incompatible with this architecture and will not install regardless of matching frequency or capacity specifications.
- Asymmetric population of the 2 slots (for example, one 32 GB and one 16 GB module) will force the system to operate in single-channel mode at the speed of the slower module, reducing available bandwidth by approximately 50 percent compared to matched-pair installation.
- The 64 GB maximum capacity ceiling means any single SO-DIMM exceeding 32 GB will remain incompatible, even if such modules become available in future DDR4 generations. The firmware and chipset do not support capacity combinations beyond this limit.
- DDR4-3200 modules sourced from third-party manufacturers may operate at reduced frequencies (DDR4-2933, DDR4-2666) if the system firmware does not recognize the higher-frequency JEDEC profile. Vendor-specific XMP profiles are unlikely to be applied by the BIOS without manual intervention.
- Installation of a single 64 GB module in one slot will leave the second slot unpopulated, eliminating dual-channel performance gains. This configuration trades throughput for maximum capacity.
