DELL Vostro 5502 RAM upgrade specifications

DELL Vostro 5000 Series 5502 laptop memory upgrade specifications include two SO-DIMM slots supporting DDR4-SDRAM memory modules. The system accommodates maximum RAM capacity of 32 GB total, with compatible memory operating at 3200 MHz frequency. Each slot accepts SO-DIMM form factor modules, enabling users to expand or upgrade the existing memory configuration to the specified maximum capacity for enhanced multitasking performance and system responsiveness.

Additional Notes

• The DELL Vostro 5502 supports PC4-25600 memory modules, which corresponds to the 3200 MHz frequency specification.
• Both memory slots accept Non-ECC unbuffered modules only, as standard laptop configurations do not support error-correcting memory.
• The 32 GB maximum capacity requires dual-channel configuration using two 16 GB modules to achieve optimal memory bandwidth.
• Single-channel operation results when only one slot is populated, reducing theoretical memory bandwidth by approximately 50 percent compared to matched dual-channel pairs.
• The system requires 1.2V DDR4 SO-DIMM modules; higher voltage DDR3L or DDR3 modules are physically incompatible and electrically unsupported.
• Memory module height must not exceed 30 mm to avoid interference with the laptop's bottom cover and internal components.
• Mixed module capacities within the two slots will function but force the system to operate in flex mode rather than true dual-channel, potentially causing asymmetric bandwidth allocation.
• Access to memory slots requires complete bottom panel removal, which involves disconnecting the battery cable to maintain warranty compliance and prevent electrical damage.
• The chipset supports CL22 latency timings at 3200 MHz, though modules with tighter timings (CL20 or lower) will downclock to match system specifications.
• Mixing memory modules from different manufacturers or with different timing parameters may result in automatic frequency reduction to the lowest common stable speed.
