HP Elitebook 645 G9 RAM upgrade specifications
The HP Elitebook 645 G9 laptop features DDR4-SDRAM memory specifications with two SO-DIMM slots for RAM upgrade capacity. Maximum compatible memory reaches 64 GB, supporting DDR4 modules operating at 3200 MHz frequency. The SO-DIMM form factor enables memory expansion within the dual slot configuration. Specifications indicate upgrade compatibility with standard DDR4-SDRAM modules meeting the 3200 MHz frequency requirement and SO-DIMM physical format for the HP 645 G9 model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
Additional Notes
- Dual channel architecture requires matching memory modules to reach peak data throughput and bridge the processor bandwidth gaps.
- The HP EliteBook 645 G9 utilizes a standard SODIMM interface which allows for tool based maintenance without proprietary hardware locks.
- Installing 32 GB modules in each of the 2 slots is necessary to reach the platform maximum of 64 GB.
- Memory modules exceeding the 3200 MHz frequency will downclock automatically due to motherboard chipset limitations.
- Physical installation of RAM does not void the standard hardware warranty if the internal components remain undamaged during the process.
- Total system latency is governed by the slower of the 2 installed modules if timings are not identical.
- Upgrading from a single module to a dual module configuration significantly improves integrated graphics performance by doubling the available memory bus width.
