HP Elitebook 835 G7 RAM upgrade specifications
HP Elitebook 835 G7 RAM upgrade specifications include DDR4-SDRAM memory compatible with 2x SO-DIMM slots. The laptop specifications support maximum memory capacity of 32 GB total. Upgrade components operate at 3200 MHz frequency. Compatible memory modules utilize SO-DIMM form factor for this Elitebook 800 series model. Specifications enable memory expansion from factory configuration to supported maximum capacity through available upgrade slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 31 January 2021 |
Additional Notes
- Dual channel memory architecture is supported only when 2 identical modules are installed to maximize integrated graphics performance.
- The HP Elitebook 835 G7 utilizes a non soldered memory configuration allowing for the replacement of both factory modules if the maximum capacity is reached.
- Installation of modules with higher frequency ratings will result in automatic downclocking to the 3200 MHz system limit due to chipset firmware restrictions.
- Operating at the 32 GB threshold requires the use of high density ranks which may slightly increase latency compared to lower capacity configurations.
- Accessing the SO-DIMM slots requires the removal of the bottom chassis panel which exposes internal components to potential electrostatic discharge.
- Physical clearance within the slim chassis restricts memory upgrades to standard height modules without integrated heat spreaders.
- Mismatched timings between different brands of memory sticks will force the system to default to the slowest common JEDEC profile to maintain stability.
