HP ENVY 17-r106ng RAM upgrade specifications
The HP ENVY 17-r106ng features DDR3L-SDRAM memory upgrade capabilities with two SO-DIMM slots supporting maximum RAM capacity of 16 GB. Compatible memory modules operate at 1600 MHz frequency. The laptop's memory specifications accommodate standard SO-DIMM form factor upgrades, allowing users to enhance system performance through RAM expansion up to the maximum supported capacity. Existing memory can be supplemented or replaced to meet performance requirements.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR3L-SDRAM |
| Frequency | 1600 MHz |
| Maximum RAM | 16 GB |
| Voltage | 1.35V (Low Voltage) |
| Number of pins | 204-pin |
| Interface | PC3L |
| PC Speed Rating | PC3L-1600 (PC3L-12800) |
| Bandwidth | 12.8 GB/s |
| Laptop Release date | 24 February 2016 |
Additional Notes
- DDR3L-SDRAM operates at reduced voltage (1.35V) compared to standard DDR3 (1.5V), restricting upgrades to DDR3L modules only; standard DDR3 DIMMs risk hardware damage if installed.
- SO-DIMM form factor limits upgrade sourcing to notebook-class memory modules; desktop DDR3L DIMMs are physically incompatible and will not seat in the 2 slots.
- 1600 MHz frequency ceiling creates a bandwidth constraint of approximately 12.8 GB/s per channel; memory modules rated above 1600 MHz will throttle to this speed, yielding no performance gain from premium-speed purchases.
- 16 GB total capacity ceiling (8 GB per slot maximum) means the system cannot exceed this threshold regardless of module density; single 16 GB SO-DIMM upgrades do not exist for DDR3L, eliminating single-stick upgrade paths.
- The 2-slot architecture provides no expansion headroom; replacing both existing modules is mandatory to upgrade, not additive expansion to existing memory.
- DDR3L memory availability has declined sharply since 2015; sourcing compatible SO-DIMM modules may require used market purchases rather than new retail stock, affecting warranty coverage and performance reliability.
