HP OMEN 15-dc0015no RAM upgrade specifications
The HP OMEN 15-dc0015no laptop features DDR4-SDRAM memory upgrade specifications. The system contains 2x SO-DIMM memory slots supporting a maximum RAM capacity of 32 GB. Compatible memory modules operate at 2666 MHz frequency and utilize SO-DIMM form factor. Upgrade options for this HP OMEN 15 series model allow for expanded memory capacity by installing compatible DDR4 modules into the available slots, with specifications supporting up to 16 GB per slot for maximum configuration.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 13 June 2018 |
Additional Notes
- SO-DIMM form factor limits upgrade options to laptop-specific memory modules; desktop DDR4 DIMMs cannot be installed regardless of matching frequency specifications.
- 2 slots with 32 GB maximum capacity indicates each slot supports 16 GB modules; mixed capacity configurations (8 GB + 16 GB) function but operate both modules at the slower module's speed.
- 2666 MHz frequency represents the validated speed for this platform; installing faster DDR4 modules (3000 MHz, 3200 MHz) results in automatic downclocking to 2666 MHz, negating speed upgrade benefits.
- Dual-channel memory architecture requires matched pairs for optimal performance; single-module installations or mismatched timings create latency penalties in CPU-to-RAM communication.
- DDR4-SDRAM's 1.2V standard voltage differs from mobile DDR4L variants (1.35V); voltage mismatches can cause boot failures or data corruption, requiring specification verification before purchase.
- Existing SODIMM modules must be physically removed to access the second slot in most compact OMEN 15 designs; simultaneous population of both slots may require partial disassembly of system components.
- 32 GB ceiling means maximum addressable capacity is fixed; no future upgrade path exists beyond this threshold within this motherboard's design constraints.
- HP OMEN warranty policies typically permit RAM replacement without voiding coverage; however, installation by non-authorized personnel may trigger warranty exclusions depending on regional terms.
