HP OMEN 15-dc0028nl RAM upgrade specifications
The HP OMEN 15-dc0028nl laptop supports DDR4-SDRAM memory upgrades via two SO-DIMM slots. Maximum RAM capacity reaches 32 GB total, with compatible modules operating at 2666 MHz frequency. Memory specifications enable users to expand from original factory configuration up to the supported maximum capacity through compatible DDR4 SO-DIMM upgrade modules.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 13 June 2018 |
Additional Notes
- Dual channel memory architecture is only achievable when installing 2 modules of identical capacity and speed.
- The system uses 260 pin physical interfaces which precludes the use of older DDR3 or desktop sized hardware.
- Integrated graphics performance scales directly with the population of the second memory slot due to increased memory bandwidth.
- Latency timings will revert to the slowest installed module if mismatched speeds are used in the 2 available slots.
- Installation of modules exceeding 2666 MHz results in automatic downclocking to the system bus limit.
- The chassis requires standard 1.2V low voltage modules to maintain thermal stability and power delivery compliance.
- Total memory capacity is limited by the motherboard firmware regardless of higher capacity 16 GB or 32 GB modules being physically available on the market.
- Accessing internal slots requires removal of the bottom base enclosure which may involve hidden screws under rubber feet.
- The 32 GB limit necessitates 2 modules of 16 GB each as the individual slot maximum.
