HP OMEN 15-ek1009na RAM upgrade specifications

HP OMEN 15-ek1009na laptop contains 2 SO-DIMM memory slots supporting DDR4-SDRAM modules. The system accommodates maximum RAM capacity of 32 GB total with compatible memory operating at 2933 MHz frequency. RAM upgrade specifications indicate SO-DIMM form factor compatibility for memory expansion and replacement configurations on this OMEN 15 series model.

Additional Notes

• The HP OMEN 15-ek1009na supports DDR4-3200 modules, though factory configuration operates at 2933 MHz. Aftermarket DDR4-3200 sticks will function but will downclock to the system's native speed, eliminating the performance advantage of higher frequency modules.
• Dual SO-DIMM architecture permits single-module upgrades without removing existing memory. Installing a higher-capacity stick in the vacant slot operates as a mixed-capacity configuration, which activates single-channel mode if the new module differs from the original in capacity or speed.
• Maximum addressable capacity of 32 GB is a hard firmware limit. The system cannot recognize a 64 GB dual-module configuration, making 2x16 GB the practical ceiling for full dual-channel bandwidth utilization.
• SO-DIMM connectors have a rated insertion cycle tolerance of 30 to 50 cycles before contact degradation occurs. Repeated upgrade attempts risk permanent socket damage, requiring professional repair outside consumer warranty scope.
• DDR4-SDRAM modules operate at fixed voltage (1.2 V nominal). Non-standard or overvolted modules (1.35 V or higher) will cause immediate boot failures or data corruption without triggering hardware error reporting, creating silent failure conditions.
• The 2933 MHz clock rate indicates memory controller firmware locked to this frequency. BIOS-level overclocking of memory frequency remains unavailable on this platform, restricting optimization to capacity and timing adjustments only.
