HP Pavilion 15-cs0997na RAM upgrade specifications
The HP Pavilion 15-cs0997na notebook contains two SO-DIMM slots for DDR4-SDRAM memory upgrades. The laptop specifications support a maximum RAM capacity of 16 GB total, with compatible memory operating at 2400 MHz frequency. Users seeking to upgrade the memory on the Pavilion 15 series model 15-cs0997na should select DDR4 SO-DIMM modules matching the specified frequency and form factor for proper compatibility and optimal performance within the stated maximum capacity limitations.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 16 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 01 June 2018 |
Additional Notes
- Dual channel memory architecture is accessible through the 2 slot configuration to improve integrated graphics performance.
- The 16 GB capacity limit across 2 slots restricts individual module density to 8 GB per socket.
- Installing modules with frequencies above 2400 MHz results in automatic downclocking to match the system bus speed.
- The SO-DIMM form factor requires 260 pin hardware for physical compatibility with the motherboard interface.
- Upgrading memory requires the removal of hidden screws located beneath the rubber feet on the bottom chassis.
- Mismatching memory speeds between the 2 slots forces the system to operate at the frequency of the slowest module.
- The 2400 MHz bus speed serves as a bandwidth bottleneck for CPU intensive tasks compared to newer DDR4 standards.
- Total memory capacity is shared with the onboard video controller which reduces the actual RAM available for system applications.
