HP Probook 450 G6 (x5) RAM upgrade specifications

HP Probook 450 G6 (x5) series laptop supports DDR4-SDRAM memory upgrades through two SO-DIMM slots. Maximum RAM capacity reaches 32 GB total. Compatible memory operates at 2400 MHz frequency. Upgrade specifications indicate SO-DIMM form factor modules are required for this model. Memory upgrade slots accommodate standard DDR4 configurations to expand system capacity.

Additional Notes

• Dual channel architecture availability provides a significant bandwidth increase for integrated graphics processing when both memory banks are populated with matched modules.
• The memory controller on the HP ProBook 450 G6 (x5) motherboards will automatically downclock higher speed 2666 MHz or 3200 MHz modules to match the system bus limitation of 2400 MHz.
• Internal hardware design requires the removal of the entire base enclosure for memory access which may involve delicate plastic clips and hidden screws under rubber feet.
• Maximum capacity constraints imply that 16 GB is the largest individual module size supported per slot and 32 GB modules will likely result in a failure to boot or POST.
• Total system latency remains dependent on the highest CAS latency rating if two mismatched modules are installed simultaneously.
• Stability for professional workloads is maintained by using Non-ECC unbuffered memory as registered or buffered server RAM is electrically incompatible with this chipset.
• The physical SO-DIMM interface necessitates 260-pin modules and prohibits the installation of older DDR3 or desktop-class DIMM hardware.
