HP ZBook G6 RAM upgrade specifications
The HP ZBook 14u G6 supports DDR4-SDRAM memory upgrades with two SO-DIMM slots for maximum capacity of 64 GB. Compatible memory modules operate at 2400 MHz frequency. Specifications indicate the upgrade slots accept standard SO-DIMM form factor memory modules. Maximum RAM capacity reaches 64 GB total across both available memory upgrade slots in the ZBook 14u G6 model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 01 May 2020 |
Additional Notes
- The HP ZBook G6 operates with 2 memory slots, limiting concurrent module configurations to 2 discrete DIMMs maximum. Configurations exceeding this quantity require removal of existing modules.
- DDR4-2400 specification indicates the platform supports synchronous operation only at 2400 MHz. Installation of faster DDR4 modules (2666, 2933, 3200 MHz) will downclock to 2400 MHz, negating performance gains from premium-speed memory.
- SO-DIMM form factor constrains module dimensions to 67.6 mm length. Standard UDIMM or RDIMM modules are physically incompatible and cannot be mechanically installed regardless of electrical compatibility.
- Maximum addressable capacity reaches 64 GB through 2x 32 GB SO-DIMM configuration. Single-slot population limits functional capacity to 32 GB; hybrid configurations (8 GB + 32 GB, 16 GB + 32 GB) leave available capacity underutilized.
- DDR4-2400 frequency represents the lower performance tier of DDR4 standards. Memory bandwidth limitation (19.2 GB/s per channel) may create secondary bottlenecks during multi-threaded workloads involving large dataset transfers or real-time data processing.
- SO-DIMM socket accessibility typically requires minimal disassembly. Manufacturer warranty generally permits user-installed memory modules from any vendor meeting DDR4 SO-DIMM SO-DIMM specifications and frequency ratings, provided installation does not exceed rated maximum capacity.
