LENOVO IdeaPad V330 RAM upgrade specifications
Lenovo IdeaPad V Series V330 laptop contains one SO-DIMM slot for memory upgrades. The system features DDR4-SDRAM memory operating at 2400 MHz frequency. Maximum supported RAM capacity reaches 20 GB through upgrade of the SO-DIMM slot. The V330 model combines on-board memory with expandable SO-DIMM slot configuration. Compatible memory upgrades utilize the SO-DIMM form factor specifications. Current memory upgrade specifications and maximum capacity support DDR4-SDRAM technology for enhanced system performance on the Lenovo V330 platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 20 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 19 November 2017 |
Additional Notes
- The 20 GB maximum capacity indicates 4 GB of soldered memory combined with a single 16 GB SO-DIMM module limit.
- The soldered RAM cannot be removed or replaced, making the onboard memory a permanent component of any configuration.
- Single-channel memory architecture limits bandwidth to approximately 19.2 GB/s compared to 38.4 GB/s available in dual-channel configurations.
- The single SO-DIMM slot prevents dual-channel operation regardless of module configuration.
- Memory-intensive applications including video editing, 3D rendering, and virtual machines will experience reduced performance due to single-channel bandwidth constraints.
- DDR4-2666 MHz or DDR4-3200 MHz modules will downclock to 2400 MHz when installed due to chipset frequency limitations.
- Access to the SO-DIMM slot requires bottom panel removal, which may void warranty seals on certain model variants.
- Asymmetric memory configuration (4 GB soldered plus variable SO-DIMM) prevents capacity balancing across channels.
- The 2400 MHz specification suggests an Intel 7th or 8th generation mobile platform with corresponding memory controller restrictions.
- Module compatibility requires DDR4 SO-DIMM with 260-pin configuration and voltage rated at 1.2V.
- Installation of non-standard voltage modules (1.35V or 1.5V) may cause POST failures or system instability.
- Maximum practical upgrade involves a single 16 GB module, as the slot cannot accommodate multiple DIMMs simultaneously.
