MSI Creator A9SE-031 RAM upgrade specifications
The MSI Creator 17M A9SE-031 laptop features DDR4-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 64 GB. Compatible memory modules operate at 2666 MHz frequency. Upgrade configurations allow installation of matched pairs up to the maximum RAM capacity. Specifications indicate SO-DIMM form factor modules are required for memory expansion on this specific laptop model from the MSI Creator 17M series.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 15 December 2019 |
Additional Notes
- The presence of 2 SO-DIMM slots requires the removal of existing modules to reach the maximum 64 GB capacity as no soldered memory is available for expansion.
- Dual channel memory architecture transitions are only achievable when installing pairs of identical capacity and timing modules to avoid bandwidth throttling.
- The MSI Creator A9SE-031 internal motherboard layout necessitates a complete bottom panel removal for physical access to the memory banks which may involve penetrating factory seals.
- Installing modules with frequencies higher than 2666 MHz results in automatic downclocking to the system bus limit rather than providing any speed advantages.
- Voltage compatibility hinges on the 1.2V DDR4 standard as the chipset lacks support for legacy high voltage or specialized low voltage overclocking profiles.
- Latency mismatches between disparate sticks trigger the motherboard to default to the slowest common denominator affecting overall rendering and processing efficiency.
