MSI Creator Z16P B12UHST-010FR RAM upgrade specifications
MSI Z16P B12UHST-010FR laptop memory upgrade specifications indicate two SO-DIMM slots supporting DDR5-SDRAM modules at 4800 MHz frequency. Maximum RAM capacity reaches 64 GB total. Creator series Z16P model accepts SO-DIMM form factor memory modules for upgrade compatibility. Current memory configuration and available slots permit expansion to specified maximum capacity limits.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 31 December 2021 |
Additional Notes
- The dual channel architecture requires symmetrical module pairs to achieve maximum theoretical memory bandwidth for rendering tasks.
- The MSI Creator Z16P B12UHST-010FR motherboard chipset limits the total addressable physical memory to 64 GB, preventing the use of high density 48 GB or 64 GB single modules.
- Installation of aftermarket modules with higher frequencies will Result in automatic downclocking to the 4800 MHz platform ceiling.
- Upgrading beyond the factory configuration necessitates the complete removal of existing modules since no vacant slots are available for expansion.
- Mixing modules with different CAS latencies will force the system to operate at the timings of the slowest installed chip, potentially increasing system instability.
- Accessing the SO-DIMM slots involves removing the bottom chassis panel, which may require piercing a factory seal sticker depending on regional service policies.
- The move to DDR5 technology introduces on-die Error Correction Code which improves data integrity during prolonged computational workloads compared to previous generations.
