MSI Gaming GE63 8SE-022CZ Raider RGB RAM upgrade specifications
The MSI GE63 8SE-022CZ Raider RGB gaming laptop features DDR4-SDRAM memory specifications with two SO-DIMM slots available for RAM upgrade. Maximum supported memory capacity reaches 32 GB total. Compatible memory modules operate at 2666 MHz frequency. Current specifications and slot configuration enable users to expand the laptop's RAM capacity by replacing or adding compatible DDR4 SO-DIMM modules. Upgrade compatibility requires DDR4-SDRAM memory modules matching the specified frequency and form factor standards for the GE series gaming platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 25 May 2019 |
Additional Notes
- The MSI GE63 8SE-022CZ Raider RGB contains 2 SO-DIMM slots with a 32 GB maximum capacity ceiling, meaning both slots must be populated to reach the upper limit, leaving no expansion headroom beyond that threshold.
- DDR4-2666 MHz memory operates at a relatively conservative frequency for 8th-generation Intel platforms, which typically support DDR4-2933 or higher, resulting in potential bandwidth underutilization if the system firmware does not enforce stricter timing parameters.
- SO-DIMM form factor requires low-profile memory modules; standard UDIMM sticks will not physically fit into the available slots regardless of electrical compatibility.
- Dual-channel architecture across 2 slots means memory replacement requires symmetric capacity pairing; installing unmatched module sizes or speeds may trigger reduced performance or stability issues despite technical compatibility.
- Upgrading beyond the factory configuration necessitates complete removal of existing modules, as SO-DIMM slots cannot accommodate additional density without replacing installed memory entirely.
- Non-ECC DDR4-SDRAM specification indicates the system uses consumer-grade memory; ECC modules will function but provide redundancy features that the hardware does not validate or enforce.
- Warranty coverage for memory upgrades depends on MSI's specific terms; third-party modules may void coverage if the manufacturer requires OEM-approved parts, creating a risk if replacement becomes necessary during the support window.
