MSI Gaming GE65 9SF-404FR Raider RAM upgrade specifications
The MSI GE65 9SF-404FR Raider gaming laptop features DDR4-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 32 GB. Compatible memory modules operate at 2666 MHz frequency. The Gaming GE series specifications enable RAM upgrades to enhance system performance on the GE65 9SF-404FR Raider model. Current memory slots accommodate SO-DIMM form factor modules for expanded multitasking and gaming capabilities within the maximum RAM constraints.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 15 December 2019 |
Additional Notes
- Dual channel memory architecture requires installing identical pairs of modules to maximize available bus bandwidth.
- The MSI GE65 9SF-404FR Raider utilizes a non-expandable slot configuration that necessitates the complete replacement of existing modules rather than adding to them for capacity increases.
- The processor architecture likely limits the memory controller to 2666 MHz regardless of higher rated modules installed.
- Latency timings should match the JEDEC standard for 2666 MHz to prevent system instability during high load gaming scenarios.
- Physical access to both SO-DIMM slots typically requires the removal of the entire lower chassis cover which involves breaking a factory seal.
- Total memory capacity is restricted by the motherboard BIOS firmware and will not recognize or address individual modules exceeding 16 GB per slot.
- Thermal constraints within the compact chassis suggest avoiding memory modules with bulky integrated heat spreaders to ensure proper clearance.
