MSI Gaming GE66 10SGS-288 Raider RAM upgrade specifications

MSI GE66 10SGS-288 Raider MSI GE66 10SGS-288 Raider MSI GE66 10SGS-288 Raider MSI GE66 10SGS-288 Raider MSI GE66 10SGS-288 Raider

The MSI GE66 10SGS-288 Raider Gaming series laptop supports DDR4-SDRAM memory upgrades via 2x SO-DIMM slots. Maximum compatible RAM capacity reaches 64 GB total, with memory operating at 3200 MHz frequency. The SO-DIMM form factor enables straightforward memory expansion for this MSI GE series model. Upgrade specifications allow for increased multitasking performance and memory-intensive application support within the Gaming family architecture.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date16 April 2021

Additional Notes

  • The dual channel architecture requires symmetrical module pairs to achieve maximum theoretical memory bandwidth.
  • The MSI GE66 10SGS-288 Raider requires small outline dual in line memory modules to fit the physical vertical clearance of the internal chassis.
  • Upgrading to the maximum capacity necessitates replacing both existing factory modules as no vacant slots remain for expansion.
  • System stability depends on using non ECC unbuffered modules to ensure compatibility with the mobile chipset logic.
  • Memory modules exceeding the specified frequency will downclock to the processor integrated memory controller limit.
  • Accessing the SO-DIMM slots requires the removal of the bottom base cover which involves penetrating a factory seal sticker in certain regions.
  • Latency performance depends on the module voltage requirements matching the fixed power delivery of the motherboard.
