MSI Gaming GE72 6QF Apache Pro 001-HID2 RAM upgrade specifications
The MSI GE72 6QF Apache Pro 001-HID2 Gaming series laptop features DDR4-SDRAM memory upgrade specifications with maximum capacity of 32 GB RAM. The system contains 2x SO-DIMM slots for memory expansion, compatible with DDR4 modules operating at 2133 MHz frequency. SO-DIMM form factor specifications define the physical dimensions for compatible upgrade modules on the GE72 6QF Apache Pro 001-HID2 platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2133 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2133 (PC4-17064) |
| Bandwidth | 17.1 GB/s |
| Laptop Release date | 15 February 2018 |
Additional Notes
- The MSI GE72 6QF Apache Pro gaming laptop operates with DDR4 memory at 2133 MHz, which represents the baseline JEDEC standard for 6th-generation Intel processors. Memory modules rated above this frequency will downclock to 2133 MHz unless BIOS settings explicitly enable XMP profiles, limiting practical performance gains from premium-speed RAM.
- With 2 SO-DIMM slots and a 32 GB ceiling, maximum capacity expansion requires 16 GB modules per slot. Single-slot upgrades from original factory configuration will leave asymmetrical memory population, potentially triggering single-channel bandwidth operation until both slots reach parity.
- The SO-DIMM form factor restricts component sourcing to laptop-grade memory only. Desktop DDR4 UDIMM modules are physically incompatible and cannot be force-fitted due to notch positioning, eliminating any possibility of salvaging surplus desktop components for this system.
- Warranty coverage during memory installation depends on whether the upgrade path follows MSI's approved specifications. Performing extraction and reinstallation of SO-DIMM modules requires careful attention to socket retention clips, as mechanical damage during removal can compromise warranty eligibility even if OEM-specification memory is installed afterward.
- The 2133 MHz specification indicates this machine ships with memory that does not support higher JEDEC profiles. Purchasing DDR4-3200 or DDR4-2666 modules will still function but without performance advantage, making such purchases economically inefficient for this particular platform generation.
