MSI Gaming GF75 9SD-018 Thin RAM upgrade specifications

MSI GF75 9SD-018 Thin MSI GF75 9SD-018 Thin MSI GF75 9SD-018 Thin MSI GF75 9SD-018 Thin MSI GF75 9SD-018 Thin

The MSI GF75 9SD-018 Thin Gaming laptop series supports DDR4-SDRAM memory upgrades through two SO-DIMM slots. The upgrade specifications accommodate a maximum RAM capacity of 64 GB total, with compatible memory operating at 2666 MHz frequency. Each slot accepts SO-DIMM form factor modules, enabling users to expand the base configuration up to the maximum supported capacity. These specifications define the memory upgrade parameters for this GF series model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date15 November 2019

Additional Notes

  • Dual channel mode requires pairs of identical modules to maintain peak memory controller bandwidth and minimize frame time variance during gaming.
  • The MSI GF75 9SD-018 Thin utilizes a mobile chipset that restricts higher clocked memory modules to downclock to the specified native frequency.
  • Reaching the maximum capacity necessitates the removal of all factory installed modules because the system board lacks soldered memory.
  • Physical access to the SO-DIMM slots requires the removal of the entire base plate which may involve penetrating a factory seal sticker depending on regional warranty policies.
  • Voltage requirements for replacement modules must remain at 1.2V to ensure compatibility with the existing power delivery system on the motherboard.
  • Latency timings should match between both slots to prevent the system from defaulting to the slowest shared JEDEC profile which increases processing overhead.
  • The slim chassis profile dictates that only standard height SO-DIMM modules fit without creating thermal pressure or interfering with the bottom cover.
