MSI Gaming GF76 12UG-049UK Katana RAM upgrade specifications
The MSI GF76 12UG-049UK Katana Gaming series laptop features two SO-DIMM slots for memory expansion. Maximum RAM capacity reaches 64 GB through DDR4-SDRAM modules operating at 3200 MHz frequency. Upgrade specifications indicate compatible DDR4 memory modules can be installed in either slot to enhance system performance. The Gaming GF series supports incremental capacity increases up to the maximum specification limit.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 22 December 2021 |
Additional Notes
- Dual channel memory configurations reach peak theoretical bandwidth only when identical modules occupy both hardware slots simultaneously.
- The 64 GB threshold represents the addressable BIOS limit through 2 high density 32 GB modules.
- Transitioning to higher frequency modules above 3200 MHz results in automatic downclocking due to chipset bus constraints.
- Internal layout requires the removal of the entire bottom chassis plate and breaking a factory seal which affects regional warranty terms.
- The MSI GF76 12UG-049UK Katana utilizes 260 pin physical interfaces that are incompatible with desktop DIMM hardware or newer DDR5 replacements.
- Heat dissipation from high performance memory increases the thermal load on the shared copper heat pipe system during simultaneous CPU and GPU utilization.
- Latency performance depends on the SPD profile compatibility as the system lacks manual XMP voltage adjustment in the standard firmware.
