MSI Gaming GL63 8SE-209 RAM upgrade specifications

MSI GL63 8SE-209 MSI GL63 8SE-209 MSI GL63 8SE-209 MSI GL63 8SE-209 MSI GL63 8SE-209

The MSI GL63 8SE-209 gaming laptop features two SO-DIMM memory slots supporting DDR4-SDRAM modules at 2400 MHz frequency. The maximum RAM capacity for this GL series model is 32 GB total. Compatible upgrade specifications require SO-DIMM form factor memory modules. The MSI GL63 8SE-209 supports memory upgrades to expand system performance, with both slots available for RAM expansion to reach maximum supported capacity. DDR4-SDRAM specifications ensure compatibility with this gaming laptop's architecture.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2400 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2400 (PC4-19200)
Bandwidth19.2 GB/s
Laptop Release date18 April 2019

Additional Notes

  • Dual channel memory architecture requires installing matched modules in both slots to maximize memory bandwidth for high frame rate gaming.
  • The 32 GB ceiling restricts the device to 16 GB modules per slot, preventing the use of high density 32 GB sticks.
  • Installing memory with frequencies exceeding 2400 MHz results in automatic downclocking to match the system bus speed.
  • Physical access to the SO-DIMM slots on the MSI Gaming GL63 8SE-209 necessitates the removal of the entire lower chassis cover, which may involve breaking a factory seal sticker.
  • The use of SO-DIMM modules precludes the installation of desktop grade UDIMM memory due to physical pin configuration and voltage differences.
  • Latency performance is governed by the slower of the two installed modules, making mismatched CAS latency ratings a potential bottleneck for CPU heavy tasks.
  • The internal layout requires strict adherence to low profile heights to ensure the bottom panel closes without applying pressure to the motherboard components.
