MSI Gaming GL75 9SD-023FR RAM upgrade specifications
MSI GL75 9SD-023FR gaming laptop memory upgrade specifications include DDR4-SDRAM compatible modules. The device features two SO-DIMM slots supporting maximum RAM capacity of 64 GB total. Native memory frequency operates at 2666 MHz. Upgrade specifications indicate SO-DIMM form factor modules required for memory expansion. Compatible DDR4 memory upgrades enable enhanced multitasking performance in the GL Series gaming platform. Maximum supported capacity supports demanding applications and gaming workloads on the GL75 9SD-023FR model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 16 August 2019 |
Additional Notes
- Dual channel mode functionality requires identical module capacities and timings across both slots to maximize memory controller throughput.
- The MSI GL75 9SD-023FR physical chassis design necessitates the removal of the entire bottom base plate to access the internal memory headers.
- Installing modules with frequencies higher than 2666 MHz results in automatic downclocking to match the native motherboard bus limitation.
- Achieving the maximum supported 64 GB capacity requires the use of high density 32 GB dual rank modules in both available sockets.
- Potential BIOS level limitations may mandate the use of JEDEC standard voltages to ensure boot stability without manual XMP profile adjustments.
- The SO-DIMM form factor prevents the installation of desktop grade UDIMM modules due to pin count and physical size variances.
- Populating only a single slot restricts the processor to single channel bandwidth which creates a bottleneck during memory intensive gaming or rendering tasks.
