MSI Gaming GP72X Leopard Pro-622 RAM upgrade specifications
MSI GP72X Leopard Pro-622 gaming laptop features DDR4-SDRAM memory upgrade capabilities with 2x SO-DIMM slots supporting maximum capacity of 32 GB. Compatible memory operates at 2400 MHz frequency using SO-DIMM form factor. Specifications enable RAM expansion for enhanced multitasking and performance in gaming and professional applications. Current memory configuration and available upgrade options depend on factory-installed modules.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 02 April 2017 |
Additional Notes
- The dual channel architecture requires matching module pairs to utilize the full memory bus width for improved frame rates in the MSI GP72X Leopard Pro-622.
- Installing high frequency modules results in automatic downclocking to the controller limit of 2400 MHz due to chipset firmware restrictions.
- Physical access to both SO-DIMM slots necessitates the removal of the entire bottom chassis plate which may involve piercing a factory seal sticker.
- The 32 GB threshold indicates a density limit of 16 GB per slot meaning 32 GB single stick modules are incompatible with this motherboard.
- Mixing modules with different CAS latencies forces the system to default to the slowest timing which increases overall memory overhead and latency.
- Non ECC unbuffered memory is mandatory as the hardware lacks the additional data lines required for error correction code functionality.
- Voltage compatibility is restricted to 1.2V standards preventing the use of older 1.35V or 1.5V DDR3L hardware.
