MSI Gaming GS75 10SF-489FR Stealth RAM upgrade specifications

MSI GS75 10SF-489FR Stealth MSI GS75 10SF-489FR Stealth MSI GS75 10SF-489FR Stealth MSI GS75 10SF-489FR Stealth MSI GS75 10SF-489FR Stealth

The MSI GS75 10SF-489FR Stealth gaming laptop features two SO-DIMM memory slots supporting DDR4-SDRAM modules at 3200 MHz frequency. Maximum RAM capacity reaches 64 GB when both slots are populated with compatible upgrades. Current memory configuration can be expanded through replacement of existing modules with higher-capacity DDR4 SO-DIMM components. Specifications indicate SO-DIMM form factor compatibility for RAM upgrade operations on the GS series model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date22 August 2020

Additional Notes

  • The dual-slot configuration necessitates the removal of existing modules to reach the maximum capacity since no memory is soldered to the mainboard.
  • The MSI GS75 10SF-489FR Stealth requires a flipped motherboard orientation for internal access which complicates the physical installation of replacement modules.
  • Operating 2 identical modules enables dual-channel mode to maximize memory bandwidth for high-frame-rate gaming and video rendering tasks.
  • Memory controllers on the 10th generation processors may downclock 3200 MHz modules to 2933 MHz depending on the specific CPU tier installed.
  • Populating both slots with 32 GB sticks to reach the 64 GB limit increases thermal density within the thin-chassis design.
  • Standard voltage 1.2V SO-DIMM kits are required to maintain stability and prevent BIOS compatibility issues during the POST process.
  • Integrated graphics performance scales directly with the speed and latency of the installed hardware when the dedicated GPU is inactive.
