MSI Gaming GS75 8SF-099FR RAM upgrade specifications
MSI GS75 8SF-099FR gaming laptop RAM upgrade specifications include DDR4-SDRAM memory compatible with 2x SO-DIMM slots. Maximum memory capacity reaches 32 GB total with 2666 MHz frequency operation. Upgrade specifications indicate SO-DIMM form factor modules for compatibility with GS series configuration. Memory specifications support RAM expansion within defined slot parameters and maximum capacity constraints of gaming notebook platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 10 May 2019 |
Additional Notes
- The motherboard architecture requires a matched pair of modules to enable dual channel memory mode and maximize internal bus bandwidth.
- The MSI GS75 8SF-099FR utilizes a flipped motherboard design where memory slots sit on the underside of the PCB, necessitating the removal of the entire board from the chassis to access the SO-DIMM sockets.
- Physical height constraints within the ultra thin chassis preclude the installation of memory modules equipped with thick integrated heat spreaders.
- Installation of modules exceeding the rated clock speed will result in an automatic downclock to the ceiling supported by the mobile chipset.
- The total memory capacity is limited by the number of available slots, meaning any capacity increase requires the replacement of existing modules rather than simple addition.
- Opening the factory chassis to reach the inverted components may involve piercing a factory seal sticker, which carries regional warranty implications for the hardware.
- Operating at the maximum supported capacity ensures sufficient overhead for concurrent execution of background system processes and high demand game engines.
