MSI Gaming GS75 Stealth 10SE-059FR RAM upgrade specifications
The MSI GS75 Stealth 10SE-059FR gaming laptop contains two SO-DIMM slots for DDR4-SDRAM memory upgrades. The system supports a maximum RAM capacity of 64 GB total, with compatible modules operating at 3200 MHz frequency. Users can upgrade the memory configuration by installing additional DDR4 SO-DIMM modules into the available slots, subject to the specified maximum capacity limitations and frequency specifications for the GS75 Stealth series.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 13 June 2020 |
Additional Notes
- Dual channel memory architecture is only achievable when both slots contain matching module capacities and timings.
- The MSI GS75 Stealth 10SE-059FR utilizes a flipped motherboard design that requires complete removal of the internal chassis components to access the SO-DIMM slots for hardware replacement.
- System thermal constraints and chipset limitations may cause 3200 MHz modules to downclock to 2933 MHz depending on the specific CPU tier installed.
- Upgrading beyond the factory configuration necessitates the use of unbuffered non-ECC modules as ECC memory will result in a failure to post.
- Populating both slots to reach the 64 GB maximum enhances bandwidth for high resolution video editing and complex 3D rendering tasks beyond standard gaming requirements.
- Physical height restrictions within the slim chassis prevent the installation of memory modules equipped with thick integrated heat spreaders.
- Warranty coverage remains intact during RAM installation provided no mechanical damage occurs to the internal ribbon cables or the fragile motherboard surface during the inverted assembly process.
