MSI Modern 14 B10RBSW-015XIT RAM upgrade specifications
MSI Modern 14 B10RBSW-015XIT laptop memory upgrade specifications include one SO-DIMM slot supporting DDR4-SDRAM at 2666 MHz frequency. Maximum compatible RAM capacity reaches 32 GB. Upgrade options utilize SO-DIMM form factor modules. Current memory configuration allows single-slot expansion for increased system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 24 June 2020 |
Additional Notes
- The presence of a single SO-DIMM slot prevents the utilization of dual-channel memory architecture, resulting in a single-channel configuration that limits peak memory bandwidth.
- Upgrading the **MSI Modern 14 B10RBSW-015XIT** to 32 GB requires the removal and replacement of the existing module since no secondary expansion slot exists for additive capacity.
- Installation of memory modules with frequencies exceeding 2666 MHz will result in automatic downclocking to match the motherboard bus limitations.
- Latency performance depends entirely on the timings of the individual replaced module due to the lack of interleaved memory processing.
- System stability for professional workloads is contingent on selecting high-density 32 GB sticks that conform to JEDEC standards rather than XMP profiles which might not be supported by the BIOS.
- Hardware modifications involve accessing the internal chassis which may require breaking a factory seal, potentially impacting regional warranty terms depending on local consumer laws.
