MSI Modern 14 B4MW-013CA RAM upgrade specifications

MSI 14 B4MW-013CA MSI 14 B4MW-013CA MSI 14 B4MW-013CA MSI 14 B4MW-013CA MSI 14 B4MW-013CA

MSI Modern 14 B4MW-013CA laptop specifications indicate 2x SO-DIMM slots compatible with DDR4-SDRAM memory modules. Maximum RAM capacity reaches 64 GB when upgraded to supported specifications. Memory operates at 3200 MHz frequency. Upgrade compatibility requires DDR4-SDRAM SO-DIMM form factor modules matching specifications for optimal performance and functionality.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date30 June 2020

Additional Notes

  • Dual channel memory architecture requires installing modules in pairs to maximize the integrated Radeon graphics performance and memory bandwidth.
  • The MSI Modern 14 B4MW-013CA motherboard utilizes a standard SO-DIMM interface which permits manual replacement of factory modules without soldering restrictions.
  • Reaching the 64 GB threshold necessitates the use of 2 high density 32 GB sticks since no additional slots exist for expansion beyond the primary configuration.
  • System stability is maintained by selecting unbuffered non-ECC modules to match the specific voltage requirements of the DDR4 standard.
  • Performance limitations occur if mismatched frequency sticks are used as the system clocks down to the lowest common denominator between the 2 slots.
  • Physical installation requires the removal of the bottom chassis cover which exposes internal components to potential electrostatic discharge during the motherboard access process.
  • Lower latency timings on aftermarket kits may result in improved system responsiveness compared to basic JEDEC standard modules provided at purchase.
