MSI Modern 15 A10M-410XFR RAM upgrade specifications
MSI Modern 15 A10M-410XFR laptop features 2x SO-DIMM memory slots supporting DDR4-SDRAM upgrade capacity. Maximum RAM specifications allow up to 64 GB total memory installation. Compatible memory modules operate at 2666 MHz frequency. Laptop RAM upgrade utilizes SO-DIMM form factor configuration. DDR4-SDRAM specifications define memory upgrade compatibility and performance parameters for MSI 15 A10M-410XFR series.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 25 July 2020 |
Additional Notes
- Dual channel architecture requires matching module capacities and frequencies to maximize memory bandwidth and Reduce latency across the system bus.
- The MSI Modern 15 A10M-410XFR utilizes a non soldered memory configuration that allows for the removal of existing modules to reach the maximum supported density.
- Installing modules with frequencies higher than 2666 MHz will result in automatic downclocking to the processor limit of the 10th generation chipset.
- Physical access to the SO-DIMM slots necessitates the removal of the entire lower chassis panel which may involve piercing a factory seal sticker in certain regions.
- High density 32 GB sticks must use the 1.2V DDR4 standard to ensure compatibility with the motherboard power delivery system without thermal throttling.
- Populating both slots with identical memory modules provides a significant performance boost for integrated graphics workloads compared to single channel configurations.
