MSI Modern 15 A5M-021XIT RAM upgrade specifications

MSI 15 A5M-021XIT MSI 15 A5M-021XIT MSI 15 A5M-021XIT MSI 15 A5M-021XIT MSI 15 A5M-021XIT

MSI Modern 15 A5M-021XIT laptop supports DDR4-SDRAM memory upgrades with two SO-DIMM slots. Maximum RAM capacity reaches 64 GB total. Compatible memory operates at 3200 MHz frequency. Upgrade specifications enable expansion from factory configuration to full 64 GB capacity through standard SO-DIMM modules. DDR4-SDRAM technology provides standard memory performance for the 15-inch Modern series platform.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date02 November 2021

Additional Notes

  • The presence of 2 physical SO-DIMM slots allows for a symmetrical dual-channel configuration which doubles the theoretical memory bandwidth compared to single-channel setups.
  • The MSI Modern 15 A5M-021XIT motherboard architecture supports high-density modules allowing for a total capacity of 64 GB though this requires replacing both factory sticks if the slots are occupied.
  • Operating at a native 3200 MHz frequency implies the hardware utilizes the standard JEDEC profile for maximum stability without requiring XMP BIOS profiles.
  • The choice of DDR4-SDRAM ensures compatibility with a wide range of third-party modules but prevents the installation of newer DDR5 hardware due to different pin counts and voltage requirements.
  • Upgrading to the maximum supported capacity minimizes data swapping to the solid state drive which extends the lifespan of the storage NAND flash.
  • Standard laptop maintenance for this specific chassis requires removing the entire bottom panel to access the memory slots which may involve navigating internal plastic clips.
