MSI Summit E15 A11SCST-088FR RAM upgrade specifications

MSI E15 A11SCST-088FR MSI E15 A11SCST-088FR MSI E15 A11SCST-088FR MSI E15 A11SCST-088FR MSI E15 A11SCST-088FR

The MSI Summit E15 A11SCST-088FR laptop features DDR4-SDRAM memory upgradeable through two SO-DIMM slots. The device supports maximum RAM capacity of 64 GB with compatible memory operating at 2666 MHz frequency. Current upgrade specifications indicate SO-DIMM form factor modules for memory expansion. DDR4 memory modules remain the standard upgrade option for this MSI E15 model, allowing users to increase system RAM capacity within the defined specifications and maximum supported capacity limits.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date04 December 2020

Additional Notes

  • The presence of 2 physical SO-DIMM slots allows for a dual-channel memory configuration which doubles the theoretical bandwidth between the processor and the system RAM.
  • The MSI Summit E15 A11SCST-088FR architecture requires 32 GB modules in each slot to reach the verified 64 GB capacity limit.
  • Installing modules with frequencies higher than 2666 MHz will result in downclocking to match the motherboard controller limitations.
  • Memory upgrades require the removal of the entire bottom chassis panel which may involve piercing a factory seal sticker in certain regions.
  • Latency performance depends on matching the CAS latency of both modules as the system will default to the timings of the slowest installed stick.
  • The integrated graphics chip shares the system memory pool meaning higher RAM capacity directly increases the maximum VRAM buffer available for graphical tasks.
  • Compatibility is restricted to non-ECC unbuffered modules as registered server memory will prevent the system from posting.
