MSI Workstation WF65 10TH-1201 RAM upgrade specifications
MSI WF65 10TH-1201 workstation features DDR4-SDRAM memory upgrade capabilities with 2x SO-DIMM slots supporting maximum RAM capacity of 64 GB. Compatible memory specifications include DDR4 modules operating at 2666 MHz frequency with SO-DIMM form factor. Upgrade configurations accommodate modular memory expansion within specified slot compatibility and maximum capacity constraints for enhanced system performance.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 22 July 2020 |
Additional Notes
- Dual channel architectural benefits require installing identical modules in both available slots to maximize memory bandwidth for professional rendering tasks.
- The processor memory controller limits higher frequency modules to the specified 2666 MHz regardless of the theoretical speed of the installed RAM.
- Reaching the maximum capacity necessitates the removal of all pre installed factory modules due to the absence of vacant expansion slots.
- Integrated graphics hardware will reserve a portion of the system memory which reduces the total amount of available RAM for the operating system.
- Upgrading the MSI WF65 10TH-1201 requires standard small outline dual in line memory modules designed for mobile platforms rather than desktop equivalents.
- Internal component access for memory replacement involves removing the bottom chassis panel which may expose delicate thermal components to static discharge.
- Non ECC memory architecture lacks the error correction capabilities required for mission critical server environments but provides sufficient stability for standard workstation workflows.
